MIL-PRF-1/1701C
Dimensions
Ltr
Inches
Millimeters
Min
Max
Min
Max
A
.013
.019
0.33
0.48
B
.142
.152
3.61
3.86
C
.394
.396
10.01
10.06
D
.651
.661
16.54
16.79
E
.952
.960
24.18
24.38
F
1.297
1.328
32.94
33.73
G
.022
.024
0.56
0.61
H
.089
.099
2.26
2.51
J
.045
.065
1.14
1.65
K
1.364
1.366
34.65
34.70
L
1.496
1.504
38.00
38.20
M
1.620
1.630
41.15
41.40
N
1.734
1.766
44.04
44.86
Q
1.563
1.594
39.70
40.49
R
1.379
1.389
35.03
35.28
S
.426
.436
10.82
11.07
T
.594
.625
15.09
15.88
U
.032
.042
0.81
1.07
V
.015
.047
0.38
1.19
FIGURE 6. Outline drawings of mating flange and gasket for tube type DOD-004.
