INCH-POUND
MIL-PRF-1/1701C
30 April 1998____
SUPERSEDING
MIL-E-1/1701B
21 June 1976
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, GAS SWITCHING
TYPE DOD-004 *
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: Dual TR with external shutters, 15,800 to 17,000 MHz, 60 kw.
ABSOLUTE RATINGS:
Ignitor
Transmitter
Parameter:
Esol
Ii
voltage
po
TA
Alt
µA dc
°C
Unit:
V dc
V dc
kw
ft
Maximum:
29
200
---
60
+125
60,000
Minimum:
21
100 1/
-850
---
-55
---
PHYSICAL CHARACTERISTICS:
Dimensions: See figures 5 and 6.
W eight: 6.0 ounces.
Mounting: 2/
TEST CONDITIONS:
Parameter:
Ignitor
Transmitter
tp
prr
F
voltage
po
Frequency
µs
±
Unit:
V dc
kw
pps
MHz
F
MHz
Test condition 1:
F1
15,800
16
Maximum:
870
---
---
---
---
F2
16,000
16
---
---
---
---
F1
F3
16,200
16
Minimum:
850
---
---
---
---
F4
16,500
16
Test condition 2:
F5
17,000
16
Maximum:
870
---
0.50
---
---
---
0.060
---
2,400
F1
Minimum:
850
---
0.30
---
---
Test condition 3:
Maximum:
870
---
1.10
---
---
---
60
---
2,400
F3
Minimum:
850
---
0.90
---
---
GENERAL:
Qualification: Required.
________
* Formerly BTR-141
AMSC N/A
1 of 12
FSC 5960
