MIL-PRF-1/1000B
Dimensions
Ltr
Inches
Millimeters
Min
Max
Min
Max
Conformance inspection
A
1.245 RAD
1.255 RAD
31.62 RAD
31.88 RAD
B
.674
.678
17.12
17.22
C
.674
.678
17.12
17.22
D
1.000 RAD
25.40 RAD
E
.735
.739
18.67
18.77
F
.735
.739
18.67
18.77
G
1.870
1.880
47.50
47.75
H
.933
.943
23.70
23.95
J
1.870
1.880
47.50
47.75
K
1.982
1.984
50.34
50.39
L
.496
.498
12.60
12.65
M
1.121
1.123
28.47
28.52
N
.164 DIA
.174 DIA
4.16 DIA
4.42 DIA
NOTES: Unless otherwise specified, tolerance on all decimal dimensions is to be ± .005.
FIGURE 8. Precision standard guide.
13
