INCH-POUND
MIL-PRF-1/1000B
17 September 1999
SUPERSEDING
MIL-E-1/1000A
5 June 1975
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, GAS SWITCHING
TYPE 6164
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: TR, bandpass, controlled phase shift, frequency range 8,500 to 9,600 MHz.
ABSOLUTE RATINGS:
Parameter:
Incident power
Ebb
prr
Du
Alt
Unit:
kw
V dc
pps
---
ft
Maximum:
---
---
1,000
0.001
10,000
Minimum:
4
-750
---
---
---
PHYSICAL CHARACTERISTICS: See figure 1.
Application:
1/
TEST CONDITIONS:
Parameter:
σ'
Incident power
tp1
tp2
prr
Ebb
Ri
F
Frequency
Unit:
µs
µs
kw
pps
V dc
Meg
MHz
---
F
MHz
±10%
±0.15
±0.15%
±25
±6%
Tolerance:
---
---
max
8,500
Test condition 1:
40
1.0
0.5
1,000
-625
3.3
1.10
F3
1
8,775
Test condition 2:
200
1.0
---
1,000
-625
3.3
---
F3
2
9,050
3
9,325
4
9,600
5
___________________________________________________________________________
GENERAL:
Qualification - Not required.
AMSC N/A
1 of 14
FSC 5960
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
For Parts Inquires call Parts Hangar, Inc (727) 493-0744
