MIL-PRF-1/999C
Dimensions
Ltr
Inches
Millimeters
Min
Max
Min
Max
Conformance inspection
A
.506
.511
12.85
12.98
B
.016
.020
0.41
0.51
C
.126
.135
3.20
3.43
D
.196
.205
4.98
5.21
G
1.006
1.012
25.56
25.70
H
1.550
1.554
39.37
39.47
J
.288
.298
7.32
7.57
K
.352
.362
8.94
9.19
L
.257
.267
6.53
6.78
Reference dimensions
.249
6.32
E
.344
8.74
F
1.122
28.50
M
.062 x .062
1.57 x 1.57
N
.031 TYP
0.79 TYP
P
.031 x 45° TYP
0.79 x 45° TYP
Q
NOTES:
1. Method of fabrication optional.
2.
Suitable clamp shall be provided to insure proper seating of tube in mount.
3.
Pressure shall be provided to press the tube against surface "Z".
4.
Surfaces "X: and "Y" shall be parallel within ±0°5'.
5.
All internal edges to have .015R inch (0.38 mm) to .031R inch (0..79 mm).
FIGURE 3. Test mount "A" details - Continued.
8
