INCH-POUND
MIL-PRF-1/999C
13 January 2012
SUPERSEDING
MIL-PRF-1/999B
27 August 1999
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, GAS SWITCHING
TYPE 6163
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: ATR, broadband, F0 = 9,050 MHz.
ABSOLUTE RATINGS:
Parameter:
Incident power
Du
TA (nonoperating)
Alt
Unit:
kw
---
°C
ft
Maximum:
250
0.001
+100
10,000
Minimum:
4
---
-40
---
PHYSICAL CHARACTERISTICS:
Dimensions:
See figure 1
Mounting position:
Any.
Test mounts:
See figures 2, 3, and 4.
Weight:
0.13 pound (approximate).
Application:
6/
TEST CONDITIONS:
σ`
Parameter:
Incident power
tp
prr
F
Frequency
μs
Unit:
kw
pps
---
MHz
Tolerance:
±5%
±0.15
±10%
Max
---
F
Max
±
Test condition 1:
4
0.5
1,000
---
F4
1
9, 050
---
Test condition 2:
20
1.0
1,000
1.02
F3
2
9,050
0.1%
Test condition 3:
200 (min)
1.0
1,000
1.2
F4
3
9,050
1.0%
4
9,050
3%
___________________________
GENERAL:
Qualification: Not required
Preproduction sample approval: Required. 1/
This specification sheet uses accept on zero defect sampling in accordance with MIL-PRF-1, table III.
AMSC N/A
FSC 5960
