MIL-PRF-1/999C
Dimensions
Ltr
Inches
mm
Min
Max
Min
Max
Conformance inspection
A
1.590 1.610
40.39
40.89
NOTES:
C
3.190 3.210
81.03
81.53
1. Method of fabrication optional.
D
3.190 3.210
81.03
81.53
F
.248
.250
6.30
6.35
2. Dimensions of socket shown on figure 3.
G
.494
.500
12.55
12.70
H
.396
.406
10.06
10.31
3. Flanges may be UG-51/U or UG-52A/U.
K
.309
.313
7.85
7.95
4. All internal edges to have .015 inch (0.38 mm) to
L
.371
.375
9.42
9.53
.031R inch (0.79 mm)
M
.394
.414
10.01
10.52
Reference dimensions
B
.50
12.70
E
10.59
268.99
J
5.81
147.57
FIGURE 2. Test mount "A" outline.
