MIL-PRF-1/1705C
Dimensions
Ltr
Inches
Millimeters
Ltr
Inches
Millimeters
Min
Max
Min
Max
Min
Max
Min
Max
A
1.860
1.890
47.24
48.00
K
.735
.739
18.67
18.77
B
.674
.678
17.12
17.22
L
1.860
1.890
47.24
48.00
C
.674
.678
17.12
17.22
M
.125-27 NPT
3.18-27 NPT
D
1.558
1.561
39.57
39.65
N
.235
.265
5.97
6.73
E
1.774
1.777
45.06
45.13
P
.985
1.015
25.02
25.78
F
.125-27 NPT
3.18-27 NPT
Q
.485
.515
12.32
13.08
G
1.235
1.265
31.37
32.13
R
.735
.765
18.67
18.77
H
1.235
1.265
31.37
32.13
S
.063
.067
16.00
1.70
J
.735
.739
18.67
18.77
T
#.8-32 x 1.5 LG
#.8-32 x 1.5 LG
NOTES:
1. Material: (Base and cover) corrosion resistance in accordance with ASTM-A484/A484M and ASTM-A582/A582M.
2. Dimensions are in inches, with millimeters equivalents provided.
3. Diameters shall be concentric within .005 T.I.R.
4. Remove all burrs, break sharp edges.
32
5. Surfaces with
finish shall be free of defects, blemishes, tool marks, scratches, or surface irregularities.
6. Passivate in accordance with MIL-F-14072 (E300).
7. This fixture is to be used for the pressurization test.
FIGURE 4. Magnetron output test fixture.
