MIL-PRF-1/1705C
Dimensions
Inches
Millimeters
Inches
Millimeters
Ltr
Min
Max
Min
Max
Ltr
Min
Max
Min
Max
Conformance inspection, part 1
Conformance inspection, part 3
B
.189
.375
4.80
9.53
C
---
6.375
---
161.93
F
.277
.287
7.04
7.29
E
---
3.875
---
98.43
K
.1865
.1895
4.74
4.81
J
3.250
3.500
82.55
88.90
L
.040
.045
1.02
1.14
Z
.938
1.080
23.83
27.43
M
---
2.250
---
57.15
AF
---
.300
---
7.62
Y
4.175
4.425
106.05
112.40
AJ
.165
---
4.19
---
AK
---
3.000
---
76.20
Nominal dimensions
AP
3.625
4.125
92.08
104.78
D
3.375
85.73
AQ
1.125
1.285
28.58
32.64
H
.164-32 UNC-2B
4.16-32 UNC-2B
AU
---
6.625
---
168.28
N
.125
3.18
BB
---
4.975
---
126.37
P
.112-40 UNC-2B x .250 Min DP
2.84-40 UNC-2B x .250 Min DP
BD
.932
1.062
23.67
26.97
U
.625
15.88
Conformance inspection, part 2
T
.688
17.48
A
2.370
2.380
60.20
60.45
AB
.600
15.24
G
1.813
1.937
46.05
49.20
AC
.050
1.27
S
.151
.161
3.84
4.09
AD
.468
11.89
AW
2.985
3.015
75.82
76.58
AE
.938
23.83
BA
2.485
2.515
63.12
63.88
AH
.188
4.78
AG
.218
5.54
AT
3.875
98.43
NOTES:
1. Metric equivalents (to the nearest 0.01 mm) are given for general information only and are based upon 1 inch = 25.4 mm.
2. W aveguide flange meeting surface, mounting plate surface area, and joints within these areas must be capable of
providing a hermetic seal.
FIGURE 1. Outline configuration of tube type 8896 - Continued.
