INCH-POUND
MIL-PRF-1/160N
16 June 2003
SUPERSEDING
MIL-PRF-1/160M
22 May 1998
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, POW ER
TYPE 7034
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: Tetrode.
See figure 1.
Mounting position: Any.
W eight: 4 ounces nominal.
ABSOLUTE RATINGS: F1 = 150 MHz; F2 = 500 MHz
Parameter
Ef
Eb
Ec1
Ec2
Ehk
Ib
Pg1
Pg2
Pp
Unit:
V ac
V dc
V dc
V dc
V dc
mA dc
W
W
W
note 2
Maximum:
C Tlg (Up to 150 MHz):
---
2,000
-250
300
250
2
12
250
± 150
C Tlg (150 to 500 MHz):
---
1,250
-250
300
250
2
12
250
± 150
Test conditions:
6.0
2,000
Adj
300
0
150
---
---
---
ABSOLUTE RATINGS: F1 = 150 MHz; F2 = 500 MHz.
Parameter:
T (base seal)
T (anode seal)
T (anode core)
tk
Unit:
sec (min)
°C note 1
°C note 1
°C note 1
Maximum:
C Tlg (Up to 150 MHz):
175
200
250
30
C Tlg (150 to 500 MHz):
175
200
250
30
Test conditions:
note 3
---
---
120
GENERAL:
Qualification - Required.
Tube type 7035 has been deleted from this tube specification sheet: use MIL-PRF-1/1331, type 7609.
