INCH-POUND
MIL-PRF-1/368G
1 October 2009
SUPERSEDING
MIL-PRF-1/368F
6 April 1999
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, GAS SWITCHING
TYPE 5865
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: TR, bandpass, frequency range 5,395 to 5,905 MHz, peak power rating 300 kw.
ABSOLUTE RATINGS:
Parameter:
Incident power
Ebb
Altitude
Unit:
kw
V dc
feet
Maximum:
300
---
10,000
Minimum:
4
-700
---
PHYSICAL CHARACTERISTICS: See figure 1.
TEST CONDITIONS:
F
Parameter:
tp1
prr
Ii
Incident
power
s
A dc
Unit:
pps
kw
---
MHz
10%
0.15
Tolerance:
---
---
Max
---
Test condition 1:
1.0
1,000
100
4
1.1:1
F3
Test condition 2:
1.0
1,000
100
70
1.1:1
F3
Frequency
(percent)
F
MHz
1
5,395
0.1
2
5,450
0.1
3
5,650
5
4
5,825
0.1
5
5,905
0.1
_______________________________________________________________________________________________________
GENERAL:
Qualification - Required.
AMSC N/A
FSC 5960
For Parts Inquires call Parts Hangar, Inc (727) 493-0744
