INCH POUND
MIL-PRF-1/22J
29 May 1998
SUPERSEDING
MIL-E-1/22H
5 March 1973
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, GAS SWITCHING
TYPES 1B35A, 1B37A, 6162, AND 5864
This specification is approved for use by all Depart
ments and Agencies of the Department of Defense.
The complete requirements for procuring the electron tubes described herein
shall consist of this document and the latest issue of Specification MIL-PRF-1.
DESCRIPTION: ATR, frequency:
1B35A - - - Fo = 9,300 MHz, incident power 250 kw
1B37A - - - Fo = 8,750 MHz
6162 - - - Fo = 9,080 MHz
5864 - - - Fo = 9,375 MHz
ABSOLUTE RATINGS:
Parameter:
Incident power
Du
TA
Alt
Unit:
kw
---
ft
C
Maximum
250
0.001
+100
10,000
Minimum:
4
---
-40
---
(See note 1) OF Table I
PHYSICAL CHARACTERISTICS: See figure 1
TEST CONDITIONS: See note 2
Parameter:
F
tp
prr
Du
Incident power
'
Unit:
MHz
pps
---
kw
---
s
Test condition 1:
1,000
0.001
200
1.2 (max)
Fo 3%
1.0 0.1
Test condition 2:
1,000
---
20
1.03
Fo 3%
1.0 0.1
_________________________________________________________________________________
GENERAL:
Qualification - Required
AMSC N/A
Page 1 of 5
FSC 5960
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited
