MIL-PRF-1/1733A(NAVY)
TABLE I. Testing and inspection.
Inspection
Limits
Inspection
Method
Conditions
Acceptance
level or
Symbol
Unit
level
code
Min
Max
Conformance inspection,
part 1
0.65
II
PPD
---
10.0
psi
1155
No voltages applied 13/
Anode water pressure
differential
Grid(1) water pressure
1155
No voltages applied 13/
0.65
II
GPD
---
6.0
psi
differential
Grid(2) water pressure
1155
No voltages applied 13/
0.65
II
SPD
---
8.0
psi
differential
Filament water pressure
1155
No voltages applied 13/
0.65
II
FPD
---
8.0
psi
differential
Cathode water pressure
1155
No voltages applied 13/
0.65
II
CPD
---
8.0
psi
differential
Electrode voltage (grid)
1261
Ebb = 15 kV dc; ec2 = 2 kv;
0.65
II
Ec1
---
-320
V dc
Ec1/ib = 2.7 a;
Ef = 0.95 V, 60 Hz;
prr = 300 H 5;
tp = 60, +5, -0 2s
Filament current
1301
Ef = 0.95 V, 60 Hz
0.65
II
If
460
530
A
Peak power output
---
Ef = 0.95 V, 60 Hz;
0.65
II
po
225
290
kw
Ebb = 15 kV dc; ec2 = 1.8 kv;
Ic1
10
---
mA dc
Ec1 = -250 H 10 V dc;
Ic2
10
---
mA dc
Power
50
---
---
pd/ib = 60 a; prr = 300 H 5;
gain
tp = 60 +5, -0 2s;
F = 400 MHz (min)
1/ 16/ 18/ 26/ 27/ 30/
Emission check
---
Peak power output;
0.65
II
po
225
---
kw
Ef/If = 450A, 60 Hz;
ec2 = 2 kv (max);
ib = 60 a (max) 29/
Perveance
---
Ef = 0.95 V, 60 Hz;
0.65
II
is
54
---
a
ec1 = ec2 = 200 v;
tp = 1.0 2s (min)
prr = 10 (min) 1/ 17/
Electrode current (grid)
1256
Ef = 0.95 V, 60 Hz;
0.65
II
Ic1
---
-50
2A dc
Eb = 6.5 kV dc;
Ec2 = 600 V dc;
Ec1/Ib = 1.0 Adc;
t = 5 minutes 19/ 25/
