MIL-PRF-1/1635C
Dimensions (see note 2)
Ltr
Inches
Millimeters
Min
Max
Min
Max
Conformance inspection, part 2
A
10.375 DIA
10.625 DIA
263.53 DIA
269.88 DIA
B
9.000 DIA
---
228.60 DIA
---
F
11.375
11.875
288.93
301.63
G
15.500
16.000
393.70
406.40
H
19.750
20.250
501.65
514.35
J
3.469
3.656
88.11
92.86
K
1.594 RAD
1.969 RAD
40.49 RAD
50.01 RAD
L
4.312 DIA
4.500 DIA
109.52 DIA
114.30 DIA
Reference dimensions (see note 3)
C
42.000 RAD
1066.80 RAD
D
11.750 RAD
298.45 RAD
E
1.000 RAD
25.40 RAD
FIGURE 1. Outline drawing of electron tube type 10ALP19 - Continued.
7
