MIL-PRF-1/1605C
Dimensions
Ltr
Inches
Millimeters
Min
Max
Min
Max
A
9.370
9.380
238.00
238.25
B
8.745
8.755
222.12
222.38
C
3.370
3.380
85.60
85.85
D
.995
1.005
25.27
25.53
E
.620
.630
15.75
16.00
F
12.680
12.690
322.07
322.23
G
16.870
16.880
428.50
428.75
H
.620 DIA
.630 DIA
15.75 DIA
16.00 DIA
J
.995 DIA
1.005 DIA
25.27 DIA
25.53 DIA
K
5.706
5.716
144.93
145.18
L
4.495
4.505
114.17
114.43
M
.745 TYP
.755 TYP
18.92 TYP
19.18 TYP
N
.138-32 UNC-2B
3.51-32UNC-2B
P
1.094
1.156
27.79
29.36
Q
.115
.135
2.92
3.43
R
.035
.055
0.89
1.40
S
.250-28UNF-2A
6.35-25UNF-2A
T
.030 x 45° CHAM
0.76 x 45° CHAM
U
.190
.210
4.83
5.33
V
.468
.531
11.89
13.49
W
.219
.281
55.63
7.14
X
.385
.395
9.78
10.03
Y
.844
.906
21.44
23.01
Z
5.052
5.062
128.32
128.57
AB
4.684
4.688
118.97
119.07
AC
4.382
4.386
111.30
111.40
AD
4.260
4.270
108.20
108.46
AE
3.670
3.770
93.22
95.76
AF
19°30'
20°30'
19°30'
20°30'
AG
.113
.118
2.87
3.00
AH
.065
.070
1.65
1.78
AJ
.169
.173
4.29
4.39
AK
.045
.055
1.14
1.40
AL
5.307
5.317
134.80
135.05
AM
3.000
3.010
76.20
76.45
AN
1.495
1.505
37.97
38.23
AP
.066 TYP
.069 TYP
1.68 TYP
1.75 TYP
AQ
.870 DIA
.880 DIA
22.10 DIA
22.35 DIA
AR
7.0575
7.0675
179.260
179.514
AS
1.3075
1.3175
33.210
33.464
AT
1.120
1.130
28.45
28.70
AU
.495
.505
12.57
12.83
AV
2.120
2.130
53.85
54.10
AW
.495
.505
12.57
12.83
AX
.995
1.005
25.27
25.53
FIGURE 3. Installation drawing (for guidance only) - Continued.
