MIL-PRF-1/1339F
Dimensions
Ltr
Millimeters
Inches
Conformance inspection, part 2
Min
Max
Min
Max
A
130.96
135.74
5.156
5.344
B
57.15
----
2.250
----
C
49.23
52.37
1.938
2.062
D
441.33
454.03
17.375
17.875
E
----
228.60
----
9.000
F
315.26
332.28
12.412
12.688
K
26.92
29.97
1.060
1.180
L
12.70
14.22
0.500
0.560
40°
50°
40°
50°
M
Conformance inspection, part 3 (periodic check)
H
Base: B12-37 (EIA)
J
Caps: J1-25 (EIA)
Reference dimensions (see note)
G
22.23
0.875
NOTE: Reference dimensions are for information only and are not required for inspection purposes.
FIGURE 1. Outline drawing of electron tube type 5AMP1A.
