INCH-POUND
MIL-PRF-1/1339F
20 May 2014
SUPERSEDING
MIL-PRF-1/1339E
17 March 2008
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, CATHODE RAY
TYPE 5AMP1A
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: Electrostatic deflection and focus.
See figure 1.
Mounting position: Any.
ABSOLUTE RATINGS:
Parameter:
Ef
Ec1
ed
Eb1
Eb2
Rg
Zd
Ehk
MegΩ
MegΩ
Unit:
V dc
V dc
v
V dc
V dc
V dc
±180
Maximum:
6.9
0
1,320
1,650
6,600
1.5
1.0
Minimum:
5.7
-200
----
----
----
----
----
----
Test condition:
6.3
Adjust
----
Focus
2,500
----
----
----
GENERAL:
Qualification - Required.
This specification sheet uses accept on zero defect sampling in accordance with MIL-PRF-1, table III.
AMSC N/A
FSC 5960
