MIL-PRF-1/1336G
TABLE I. Testing and inspection - Continued.
Inspection
Method
Conditions
Acceptance
Symbol
Limits
Unit
MIL-STD-1311
Level 13/
Min
Max
Conformance inspection,
part 2 - Continued
---
---
---
---
---
1111
Base pin solder depth
Permanence of marking
1105
---
---
---
---
---
Conformance inspection,
part 3
---
---
---
---
---
Ef = 7.0 V;
1506
Heater-cycling life
Ehk = 300 V ac;
Ec2 = Eb = 0;
1 minute "on"
4 minutes "off"
Heater-cycling life-test
---
end points
Heater cathode
1336
Ehk = 450 V dc
---
Ihk
---
150
µA dc
leakage
Heater current
1301
---
If
1.4
2.0
A
---
---
---
---
---
Life test
---
Group B;
pulse operation;
Ebb = 3,500 V dc;
Ecc2 = 800 V dc;
eo = 300 v;
tp = 4 µs;
prr = 250;
R1 = 500 ohms ± 5
percent
12/
Life-test end point
(500 hours)
a
---
3.75
Ebb = 420 V dc;
ib
1356
---
Grid-pulse operation
Ecc2 = 800 V dc;
Ecc1 = -150 V dc;
egy = 155 v 8/
(test in accordance with
figure 4)
1/ Instantaneous anode voltage due to transient shall not exceed 5,000 volts. Series resistance shall be inserted in the power supply
sufficient to limit the short circuit current to less than 0.5 ampere. W ith a screen potential not exceeding 400 V dc and when no
instantaneous voltage due to transient is present (essentially resistance anode load), a maximum anode potential of 4,500 V dc may
be used.
2/ Instantaneous negative grid voltage due to transient shall not exceed -500 volts. Series resistance shall be inserted in the power
supply sufficient to limit the short circuit current to less than 0.5 ampere.
3/ Series resistance shall be inserted in the power supply sufficient to limit the short circuit current to less than 0.5 ampere.
4
