MIL-PRF-1/1005E
Dimensions
Ltr
Inches
Millimeters
Min
Max
Min
Max
Qualification inspection
M
Bulb contact: J1-21
N
Base: B6-63
Conformance inspection, part 2
A
10.380
10.620
263.65
269.75
B
4.500
---
114.30
---
C
1.380
1.500
35.05
38.10
D
16.560
17.310
420.62
439.67
F
9.250
9.620
234.95
244.35
G
6.880
7.620
174.75
193.55
H
---
.190
---
4.83
Reference dimensions (see note 5)
J
42.000
1066.80
K
.380
9.65
L
20.000
508.00
NOTES:
1. The minimum useful screen radius.
2.
The base shall be a small shell duodecal 6-pin, B6-63.
3.
Dimension C applies to entire length of neck below the reference line. The reference line is determined by the point
where a gauge 1.500 +.003 inch (38.10 +0.08 mm) inside diameter and 2 inches in length will stop against the bulb
body.
4.
Do not handle tube by the part of the bulb having the anti-corona coating.
5.
Reference dimensions are for information only and are not required for inspection purposes.
FIGURE 1. Outline drawing of electron tube type 10WP7A - Continued.
