INCH-POUND
MIL-PRF-1/1005E
3 February 2012
SUPERSEDING
MIL-PRF-1/1005D
27 August 1999
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, CATHODE RAY
TYPE 10WP7A *
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: Magnetic deflection and electrostatic focus, aluminized screen.
DIMENSIONS AND PIN CONNECTIONS: See figure 1.
ABSOLUTE RATINGS:
Parameter:
Ef
Ec1
Ec2
Eb1
Eb2
Rg
Ehk
Alt
MegΩ
Unit:
V
V dc
V dc
V dc
V dc
V dc
ft
Maximum:
6.9
0, -200
600
900
13,200
1/
±180
80,000
Minimum:
5.7
---
---
-450
7,000
---
---
---
Test conditions:
6.3
Adjust
300
Focus
10,000
---
---
---
See footnotes at end of table I.
___________________________
GENERAL:
Qualification: Required.
This specification sheet uses accept on zero defect sampling in accordance with MIL-PRF-1, table III.
_________
* Replaces tube types 10WP7 and MIS 12750.
AMSC N/A
FSC 5960
