MIL-DTL-75K
3.3.4.1 Level A. Electron tubes, packed as specified in 3.3.1, shall be unitized on pallets with a wood
cap (storage aid 5) positioned over each load.
3.3.4.2 Level B. Electron tubes, packed as specified in 3.3.2, shall be unitized as specified in 3.3.4.1,
except that weather resistant fiberboard caps (storage aid 4) shall be used in lieu of wood caps.
3.3.4.3 Minimal packing. Electron tubes, packed as specified in 3.3.3, shall be unitized as specified in
3.3.4.2 except that the fiberboard caps shall be class domestic.
3.3.5 Intermediate packs. Electron tubes, unit packed in containers less than 30 cubic inches in size
(see 3.2.4.1), shall be further packaged in units of five packs each in an open top box or sleeve which
provides a sufficiently tight fit to prevent the individual unit packs from falling out during handling.
Accessories, which are not unit packed in boxes (see 3.2.4.6), shall be placed in intermediate containers
conforming to variety 2 of PPP-B-566 or PPP-B-676. All intermediate containers shall be uniform in size,
shape, and quantities, and shall be of minimum tare and cube and shall contain multiples of 5 unit packs,
not to exceed 100 unit packs. No intermediate packs are required when the total quantity shipped to a
single destination is less than 100 unit packs.
3.4 Marking. In addition to any other identification marking and special marking required by the
contract (see 6.2), and except as specified herein, each unit pack, intermediate and exterior container,
and unitized load shall be marked in accordance with MIL-STD-129.
3.4.1 Additional identification marking. The electron tube type number together with the manufacturer's
part or identifying number (MFR/PIN) and the Commercial and Government Entity (CAGE) code, shall be
marked on interior and exterior containers as specified in MIL-STD-129. The alternate single label for
small packs may be used at the option of the contractor for packaging group 1 tubes (see figure 1).
FROM:
NSN___________________________________
CAGE_____________MFR/PIN_____________
ELECTRON TUBES
(SPACE FOR QUANTITY AND
___UNIT OF ISSUE)______________________
(SPACE FOR CONTRACT NUMBER)_________
TO:
(SPACE FOR PRES./PACKING
____LEVELS AND DATE PACKED)__________
WT.________________CU.________________
TYPE NO. (IF APPLICABLE)_______________
(SPACE FOR SPECIAL MARKING)
FIGURE 1. Alternate single label for small packs.
8
