INCH-POUND
MIL-DTL-24251F
11 July 2013
SUPERSEDING
MIL-DTL-24251E
15 February 2008
DETAIL SPECIFICATION
SHIELDS, RETAINERS (BASES), AND ADAPTERS,
ELECTRON TUBE, HEAT DISSIPATING
GENERAL SPECIFICATION FOR
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers the general requirements for heat dissipating electron tube shields,
associated retainer (bases), and adapters for use in electronic equipment (see 6.1).
1.2 Part or Identifying Number (PIN). The PIN (when applicable) consists of the letter M, the basic number of the
specification sheet, and an assigned dash number (see 3.1), as shown in the following example:
M24251
/XX
-XXXX
Designator
Specification
Dash number
sheet number
(See specification sheet)
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3 and 4 of this specification. This
section does not include documents cited in other sections of this specification or recommended for additional
information or as examples. While every effort has been made to ensure the completeness of this list, document
users are cautioned that they must meet all specified requirements documents cited in sections 3 and 4 of this
specification, whether or not they are listed.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a
part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are
those cited in the solicitation or contract (see 6.2).
DEPARTMENT OF DEFENSE SPECIFICATIONS
-
Sockets and Accessories for Plug-in Electronic Components, General
Specification for.
Shield, Electron Tube, Heat Dissipating, 7 and 9 Pin, Miniature (Split Shell)
(Inactive for New Design)
-
Retainer (Base), and Adapter, Electron Tube, Heat Dissipating, 7 and 9 Pin,
Miniature
Shield, Electron Tube, Heat Dissipating, 7 and 9 Pin, Miniature (Open Sides)
Shield, Electron Tube, Heat Dissipating 7 and 9 Pin, Miniature (Retrofit Type
Only)
