INCH-POUND
MIL-PRF-1/970F
23 November 2010
SUPERSEDING
MIL-PRF-1/970E
27 August 1999
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, GAS SWITCHING
TYPE 1B58A
This specification is approved for use by all Departments and
Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: TR, bandpass, frequency range 2,664 to 2,964 MHz, incident power 750 kW.
ABSOLUTE RATINGS:
Incident power
Ebb (open circuit)
Alt
Parameter:
Unit:
kW
V dc
ft
Maximum:
---
---
10,000
Minimum:
10
-700
---
PHYSICAL CHARACTERISTICS: See figure 1.
TEST CONDITIONS:
Parameter:
F
tp1
tp2
prr
Du
Incident power
li
Ri
s
A dc
Meg
s
pps
---
kW
Unit:
MHz
0.5 0.15
200 10
F4 0.5%
1.0 0.15
1,000
---
200
1.6
Test condition 1:
F4 0.5%
Test condition 2:
1.0
---
1,000
0.001
50
200
1.6
F4 0.5%
750 10%
200
1.6
Test condition 3:
---
---
---
0.0008
Test frequencies
MHz tolerance 0.1%
F
1
2664
2
2689
3
2714
4
2802
5
2914
6
2939
7
2964
GENERAL:
Qualification: Required.
AMSC N/A
FSC 5960
