MIL-PRF-1/964E
Dimensions
Ltr
Inches
Millimeters
Min
Max
Min
Max
Conformance inspection, part 1
A
---
.750
---
19.05
B
.607
.617
15.42
15.67
L
---
1.625
---
41.28
Conformance inspection, part 2
D
1.216
1.224
30.89
31.09
G
1.276
1.284
32.41
32.61
H
.085 R
.095 R
2.16 R
2.41 R
M
---
1.422
---
36.12
N
---
.530 DIA
---
13.46 DIA
Conformance inspection, part 2
C
1.610
1.640
40.89
41.66
E
.608
.612
15.44
15.54
F
.638
.642
16.21
16.31
K
1.610
1.640
40.89
41.66
P
.031
.062
0.79
1.57
NOTE: Exhaust tube shall not extend beyond flange.
FIGURE 1. Outline drawing of electron tube type 6378.
