INCH-POUND
MIL-PRF-1/964E
13 January 2012
SUPERSEDING
MIL-PRF-1/964D
27 August 1999
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, GAS SWITCHING
TYPE 6378
This specification is approved for use by all Departments and
Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: TR, tunable, frequency range 8.49 to 9.6 GHz.
ABSOLUTE RATINGS:
Parameter:
po transmitter
Ebb (open circuit)
Du
li
Alt
TA
μA dc
Unit:
kW
V dc
---
ft
°C
Maximum:
30
---
0.001
200
10,000
+100
Minimum:
---
-500
---
100
---
-40
PHYSICAL CHARACTERISTICS:
Dimensions:
See figure 1
Weight:
5 ounces (approximately).
TEST CONDITIONS:
Parameter:
Ebb
li
po
tp
Du
Ri
Test
μA dc
μs
MΩ
Unit:
V dc
kW
---
frequencies
Tolerance:
---
---
±10%
±10%
---
---
Test 1:
-500
---
---
---
---
1.25
F1
8.490 GHz ±.01 %
Test 2:
---
100
---
---
---
1.25
F2
9.375 GHz ±.01 %
Test 3:
-500
---
30
1.0
0.001
1.25
F3
9.600 GHz ±.01 %
Test 4:
---
100
30
0.5
0.0005
1.25
Test 5:
---
100
10
0.5
0.0005
1.25
See footnotes at end of table I.
___________________________
GENERAL:
Qualification: Not required.
This specification sheet uses accept on zero defect sampling in accordance with MIL-PRF-1, table III.
AMSC N/A
FSC 5960
