INCH-POUND
MIL-PRF-1/877E
27 March 2012
SUPERSEDING
MIL-PRF-1/877D
21 September 1999
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, POWER, TYPE 100TH
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: Triode.
See figure 1.
Weight: 4-ounces (113.4 grams) nominal.
Mounting position: Vertical.
ABSOLUTE RATINGS: C Telegraphy
Parameter:
F1
Ef
Eb
Ec
Ib
Ic
Pp
MHz
V
V dc
V dc
W
Unit:
mA dc
mA dc
Maximum:
40
5.25
3,000
-210
225
50
100
---
---
---
---
---
---
Minimum:
4.75
---
---
---
Test conditions:
5.0 V ac
2,500
Adjust
40
See footnotes at end of table I.
GENERAL:
Qualification: Not required.
This specification sheet uses accept on zero defect sampling in accordance with MIL-PRF-1, table III.
AMSC N/A
FSC 5960
