MIL-PRF-1/868F
With top surface of washer (grid rf contact) in contact with surface 1 of gage
and with lower edge of washer (grid rf contact) in contact with surface 2 of gage,
external glass surface 3 of tube shall not be in contact with gage at any point.
Equivalent gaging procedure any be used.
GAGING PROCEDURE, GLASS SURFACE
FIGURE 1. Outline drawing of electron tube type 2C40A.
5
