MIL-PRF-1/849G
TABLE I. Testing and inspection.
Limits
Inspection
Method
Notes
Test
Conditions
Symbol
Min
Max
Unit
Conformance inspection,
part 1 - Continued
RF bandwidth
4308
15/ 16/ 21/
1
F = F1 to F5
BW
----
2.0/tpc
MHz
2
F = F1 to F5
BW
----
3.0/tpc
MHz
Minor lobe ratio
4308
----
1
Ratio
8
----
dB
Stability
4315
15/ 23/
1, 2
F = F1 to F5
MP
----
1.0
%
Starting stability
4315
5/ 21/ 23/
2
F = F1
MP
----
1.0
%
Pulse voltage
4306
----
2
F = F5
epy
13.5
16.5
kv
Power output
4250
----
2
t = 300 (max);
Po
65
----
W
F = F1, F3, F5
Conformance inspection,
part 2
Variable-frequency
1031
2/ 6/ 32/
----
No voltages applied
----
----
----
----
vibration
Operating torque or force
4223
10/
----
TA = -50qC
Torque
----
25
in.-oz
Torque
----
15
in.-oz
TA = +125qC;
no voltages applied
Resettability
4223
13/
1
F = 9,550 r 50 MHz
'F
----
10
MHz
Frequency pulling figure
4310
----
1
F = F1 to F5, in 100 MHz
'F
----
15
MHz
increments
Power output
4250
16/
2
F = F1 to F5
Po
65
----
W
Heater-voltage sensitivity
----
25/
1, 2
----
----
----
----
Conformance inspection,
part 3
Life test
----
3/ 26/ 27/
----
Group C;
----
1,334
----
Cycles
VSWR = 1.5:1 (min)
t
400
----
hrs
Life-tests end points:
----
Power output
4250
28/
2
Po
50
----
W
RF bandwidth
4308
28/
2
BW
----
3.0/tpc
MHz
Minor lobe ratio
4308
28/
1
Ratio
6
----
dB
Stability
4315
28/
1, 2
MP
----
2.0
%
Resettability
4223
28/ 29/
----
'F
----
50
MHz
See notes at end of table.
