MIL-PRF-1/810E
TABLE I. Testing and inspection.
Acceptance
Limits
Inspection
Method
Conditions
Level 10/
Symbol
Unit
Min
Max
Conformance inspection,
part 1
Voltage breakdown
5201
0.65
---
---
---
---
Voltage breakdown
5201
0.65
---
---
---
---
(electrostatic types)
Ib3 = 50 µA dc 9/
Gas "cross"
5206
0.65
---
---
---
---
Screen and faceplate
5106
0.65
---
---
---
---
blemishes
Ib3 = 25 µA dc
ĆEc1
Modulation
5223
0.65
---
35
V dc
Spot position (electro-
5231
0.65
---
---
15
mm
static deflection)
Spot displacement
5231
0.65
Displ
---
10
mm
(leakage)
Grid cutoff voltage
5241
0.65
Ec1
-35
-55
V dc
Pattern distortion
---
7/
0.65
---
---
---
---
µA dc
Grid No. 1 leakage current
5251
0.65
Ic1
---
3
µA dc
Anode No. 1 leakage
5251
0.65
Ib1
---
5
current
µA dc
Anode No. 2 leakage
5251
0.65
Ib2
---
5
current
Conformation inspection
part 2
Heater current
1301
6.5
If
540
660
mA
µA dc
Electrode current
5201
6.5
Ib1
-15
10
(anode No. 1)
Ib3 = 50 µA dc 4/
µA dc
Electrode current
5201
6.5
Ik
---
1,000
(cathode)
Base alignment
5101
+3D4, pin No. 5
6.5
---
---
---
---
(electrostatic types)
Side terminal alignment
5101
+3D4
6.5
---
---
---
---
(electrostatic types)
5101
Pin No. 5
6.5
---
---
---
---
Side terminal and base
alignment
(electrostatic types)
Neck and base alignment
5101
6.5
---
---
---
---
(electrostatic types)
Angle between traces
5101
6.5
---
89
91
Degrees
See footnotes at end of table.
2
