INCH-POUND
MIL-PRF-1/796D
13 January 2012
SUPERSEDING
MIL-PRF-1/796C
23 July 1999
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, GAS SWITCHING
TYPE 6024
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: ATR, waveguide type, F = 2,800 MHz, peak incident power 1.0 kw.
ABSOLUTE RATINGS:
Parameter:
Transmitter Po
TA
Alt
°C
Unit:
kw
ft
Maximum:
1,000
+100
10,000
Minimum:
20
-40
---
PHYSICAL CHARACTERISTICS:
Dimensions:
See figure 1
Mounting position:
Any 2/
TEST CONDITIONS:
Parameter:
Transmitter Po
tp
Du
VSWR
µs
Unit:
kw
---
---
Test 1:
1.0 ±10%
20
0.001
1.05
Test 2:
1.0 ±10%
750
0.001
1.20
F = 2,800 ± 5.0%
Test frequency:
See footnotes at end of table I.
___________________________
GENERAL:
Qualification: Required.
This specification sheet uses accept on zero defect sampling in accordance with MIL-PRF-1, table III.
AMSC N/A
FSC 5960
