MIL-PRF-1/747F
Dimensions
Millimeters
Ltr
Inches
Max
Min
Max
Min
Qualification inspection
B
2.953
3.047
75.01
77.39
G
Base: D8-1 (EIA) (see note 4)
P
---
1.516
---
38.51
Conformance inspection, part 2
A
8.750
9.000
222.25
222.60
C
---
1.125 DIA
---
28.57 DIA
D
1.375
---
34.93
---
Q
.563
---
14.30
---
Reference dimensions (see note 1)
E
3.879
98.53
F
30.000 R
1524.00 R
H
35.500 R
901.70 R
J
.188
4.78
K
.188 R
4.78 R
L
.246
6.25
M
1.000 R
25.40 R
N
10.000 R
254.00 R
FIGURE 1. Outline drawing of electron tube type 3XP1 - Continued.
