INCH-POUND
MIL-PRF-1/747F
21 June 2011___
SUPERSEDING
MIL-PRF-1/747E
22 July 1999
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, CATHODE RAY
TYPE 3XP1
This specification is approved for use by all Departments and
Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: Electrostatic deflection and focus.
DIMENSIONS AND PIN CONNECTIONS: See figure 1.
ABSOLUTE RATINGS:
Light
Parameter:
Ef
Ec1
ed
Eb1
Eb2
output
Rg
Zd
Alt
Unit:
MegΩ
MegΩ
V
V dc
v
V dc
V dc
ftL
ft
Maximum
2,750
1,100
550
10,000
0, -200
1.0
6.9
---
1.5
Minimum
---
---
---
---
---
5.7
---
1,000 1/
20 2/
Test conditions:
6.3
Adj
---
Focus
2,000
---
---
---
---
See footnotes at end of table I.
__________________________________________________________________________________________
GENERAL:
Qualification: Not required.
This specification sheet uses accept on zero defect sampling in accordance with MIL-PRF-1, table III.
AMSC N/A
FSC 5960
