INCH-POUND
MIL-PRF-1/66C
6 July 1999
SUPERSEDING
MIL-E-1/66B
14 January 1975
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, CATHODE RAY
TYPE 7BP7A
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: Magnetic deflection and focus.
PIN CONNECTIONS AND DIMENSIONS: See figure 1.
ABSOLUTE RATINGS:
Parameter:
Ef
Ec1
Ec2
Eb1
Ehk
Rg1
Alt
Unit:
V
V dc
V dc
V dc
V dc
Meg
ft
Maximum:
6.9
0
770
8,800
-125
note 1
10,000
Minimum:
5.7
-180
---
4,000
---
---
---
Test conditions:
6.3
Adj
250
4,000
---
---
---
GENERAL:
Qualification - Required. See note 2
AMSC N/A
1 of 5
FSC 5960
