MIL-PRF-1/594B
TABLE I. Testing and inspection.
Inspection
Method
Notes
Conditions
Symbol
Limits
Limits
Units
Min
Max
Qualification inspection
Neck and bulb alignment
5101
Diam
2.25
---
Inch
---
(electrostatic types)
Cathode illumination
5216
---
---
---
---
---
Base material insulating
1216
---
---
---
---
---
Zone 5 (minimum)
quality
Deflection factor
5248
---
---
---
---
---
uniformity
Direct-interelectrode
1331
10.5
Cg1
---
---
pF
Control grid to all cathode
capacitance
Ck
---
10.5
pF
Cathode to all
C1D2
---
4
pF
D1 to D2
C3D4
---
2.8
pF
D3 to D4
---
15
CD1
pF
D1 to all
---
CD3
12
pF
D3 to all
---
CD1
13
pF
D1 to all except D2
---
CD2
13
pF
D2 to all except D1
---
CD3
8
pF
D3 to all except D4
---
CD4
8.3
pF
D4 to all except D3
Pressure (implosion)
---
---
---
1141
---
---
Vibration
---
Width
mm
1.0
5111
---
Conformance inspection,
part 1
Voltage breakdown
5201
---
---
---
---
---
Voltage breakdown
5201
---
---
---
---
---
(electrostatic types)
Gas "cross"
5206
1
Light = 5 fL
---
---
---
---
Bulb, screen and faceplate
5106
---
---
---
---
---
quality
Light output
5221
1
Light
5.0
---
fL
Modulation
5223
---
Light = 5 fL
---
40
V dc
Ec
Spot position (electrostatic
5231
---
---
15
mm
---
deflection)
Spot displacement
5231
---
---
7
mm
---
5241
Grid cutoff voltage
---
Ec1
-22.5
-67.5
V dc
5251
Grid No. 1 leakage
---
---
---
---
---
current
5251
Anode No. 2 leakage
---
---
---
---
---
current
See footnotes at end of table.
2
