INCH POUND
MIL-PRF-1/594B
16 February 1999
SUPERSEDING
MIL-E-1/594A
14 January 1975
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, CATHODE RAY
TYPE 3BP1A
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: Electrostatic deflection and focus.
DIMENSIONS AND PIN CONNECTIONS: See figure 1.
ABSOLUTE RATINGS:
Parameter:
Ef
Ec1
ed
Eb1
Eb2
Light output
Rg
Zd
Ehk
Alt
Unit:
V
V dc
v
V dc
V dc
fL
Meg
Meg
V dc
ft
Maximum:
6.9
0
550
1,100
2,200
---
1.5
1.0
-125
10,000
Minimum:
5.7
-200
---
---
1,200
5.0
---
---
---
---
Test conditions:
6.3
Adj
---
---
1,500
---
---
---
---
---
____________________________________________________________________________________________
GENERAL:
Qualification - Required.
AMSC N/A
1 of 5
FSC 5960
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
