MIL-PRF-1/36J
A
B
SEE
NOTE 1
M
K
INTERNAL
G
J
CONNECTIONS
L
F
D3
D4
7
8
a
2
N
9
a
D2
3
10
5
H
D1
11
a
4
1
D
C
12
3
NC
14
2
THE BULB SHALL
g
1
BE A J24G TYPE
n
k
n
P
Dimensions - continued.
Dimensions (see note b/)
Conformance inspection, part 3
Minimum
Maximum
(See note 9/)
Ltr
in
mm
in
mm
N
Bulb contact: J1-22
Conformance inspection, part 2
P
Base: B12-37
Reference dimensions (see note c/)
A
2.94
74.7
3.06
77.7
in
mm
B
1.37
34.8
H
1.62
41.1
C
1.94
49.3
2.06
52.3
J
8.00 R
203.2 R
K
.25 R
6.4 R
D
9.75
247.6
10.25
260.4
L
12.44 R
316.0 R
F
3.75
95.2
4.00
101.6
M
.35
8.9
G
1.50
38.1
2.00
50.8
NOTES:
a/
The minimum useful screen radius shall not be less than 1.375 inches (34.92 mm).
b/
Metric equivalents are given for general information only and are based upon 1.00 inch = 25.4 mm.
c/
Reference dimensions are for information only and are not required for inspection purposes.
FIGURE 1. Outline drawing of electron tube types 3JP1, 3JP2, 3JP7, 3JP11, and 3JP12.
7
