INCH-POUND
MIL-PRF-1/267G
20 May 2014
SUPERSEDING
MIL-PRF-1/267F
20 March 2007
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, CATHODE RAY
TYPES 3WP1 AND 3WP2
Inactive for new design
after 7 March 1997
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: Electrostatic deflection and focus.
PIN CONNECTIONS AND DIMENSIONS: See figure 1.
ABSOLUTE RATINGS:
Parameter:
Ef
Ec1
ed
Eb1
Eb2
Rg
Zd
Ehk
Alt
MegΩ
MegΩ
Unit:
V
V dc
V dc
V dc
V dc
V dc
ft
±180
Maximum:
6.9
0, -200
550
1,100
2,750
1.5
1.0
30,000
Minimum:
5.7
---
---
---
1,000
---
---
---
---
Test conditions:
6.3
Adjust
---
Focus
1,500
---
---
---
---
GENERAL:
Qualification - Required.
This specification sheet uses accept on zero defect sampling in accordance with MIL-PRF-1, table III.
AMSC N/A
FSC 5960
