INCH POUND
MIL-PRF-1/211G
16 June 2003
SUPERSEDING
MIL-PRF-1/211F
26 June 1998
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, POW ER
TYPE 3C24
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: Triode.
See figure 1.
Mounting position: Vertical, base down or up.
W eight: 1.5-ounces nominal (42.5 grams).
ABSOLUTE RATINGS: C telegraphy.
Parameter:
F1
Ef
Eb
Ec
Ib
Ic
Pp
Unit:
MHz
V ac
kV dc
V dc
mA dc
mA dc
W
Maximum:
60
6.6
2.0
-500
75
25
25
Minimum:
---
6.0
---
---
---
---
---
Test conditions:
---
6.3
1.0
Adjust
35
---
---
GENERAL:
Qualification - required.
AMSC N/A
1 of 5
FSC 5960
DISTRIBUTION STATEMENT A: Approved for public release, distribution is unlimited.
