MIL-PRF-1/1655E
TABLE I. Test conditions - Continued.
Limits
MIL-
Acceptance
Unit
STD-
Requirement or test
Notes
Conditions
level
Symbol
1311
(see note 13)
Min
Max
Method
Conformance
inspection, part 2
-Continued
ĆIb
1256
Electrode current (1)
2.5
---
25
mA dc
(anode) difference
between sections
1031
Sweep-frequency
4,10
Rk = 0;
6.5
Ep
---
500
mV ac
vibration
Rp = 2,000 ohms;
Ec = -7 V dc;
F = 50 to 500 Hz;
2.5 G
1101
Secureness of base,
---
---
---
---
---
cap, or insert
1111
Base pin solder depth
---
---
---
---
---
1041
Shock
3,4
450 G;
---
---
---
---
---
Ehk = +450 V dc;
Ec = -7 V dc;
Rp = 2,000 ohms;
Rk = 0
1031
Sweep-frequency
10
F = 50 to 500 Hz;
6.5
---
---
---
---
vibration fatigue
2.5 G; Ef = 6.3 V;
no other voltages
applied (except
t = 48 hours)
See footnotes at end of table.
4
