INCH-POUND
MIL-PRF-1/1655E
26 April 2005
SUPERSEDING
MIL-E-1/1655D
30 April 1988
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, RECEIVING
TYPE 6080WC
This specification sheet is inactive for
new design after 11 August 2000.
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the product described
herein shall consist of this document and MIL-PRF-1.
DESCRIPTION: Twin triode, low Mu
Outline
- - - See figure 1.
Base
- - - B8-98 (glass-bonded mica).
Envelope - - - T12.
Cathode - - - Coated unipotential.
Base connections:
Pin No. - - - 1 2 3 4 5
6
7
8
Element - - - 2g 2a 2k 1g 1a
1k
h
h
ABSOLUTE-MAXIMUM RATINGS:
Parameter:
Ef
Eb
Ec
Ehk
Rk/k
Rg/g
Ic/g
Ik/k
Pp/p
TE
Alt
Meg Ω
°C
Unit:
V
V dc
V dc
v
Ohms
mA dc mA dc
W
ft
Maximum:
6.6
250
0
450
---
5.0
200
13
300 (see note 2)
(see note 1)
Minimum:
6.0
---
---
---
---
---
---
---
---
---
Test
conditions:
6.3
135
0
---
250
---
---
---
---
---
---
GENERAL:
Qualification: Not required.
AMSC N/A
FSC 5960
