INCH-POUND
MIL-PRF-1/1609C
17 August 2004
SUPERSEDING
MIL-PRF-1/1609B
26 July 1999
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, VOLTAGE REGULATOR
TYPE 8515
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: Corona discharge.
See figure 1.
Mounting position: Any.
W eight: 0.5 ounce nominal.
ABSOLUTE RATINGS:
Parameter:
Ez
Eb
Ib
TA
Unit:
V dc
V dc
µA dc
°C
Maximum:
1,760
1,645
800
+85
Minimum:
---
1,550
20
-55
Test conditions:
---
---
100
---
See footnotes at end of table I.
____________________________________________________________________________________________
GENERAL:
First article testing: Required. 7/
Holding period (MIL-STD-1311) t = 7 days.
AMSC N/A
FSC 5960
