INCH-POUND
MIL-PRF-1/1424C
16 July 2004
SUPERSEDING
MIL-PRF-1/1424B(NAVY)
18 June 1999
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, POW ER
TYPE 6303A
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION:
Diode, rectifier.
Outline -
See figure 1.
Base -
A4-18.
Cap -
See figure 1.
Cathode - Bonded thoria tungsten filament.
Pin Number:
1
2
3
4
Cap
Element:
nc
f
f
nc
a
ABSOLUTE-MAXIMUM RATINGS:
Parameter:
Ef
epx
ib
Ib
Ieff
Pp
Alt
Unit:
V ac
kv
a
mA dc
A ac
W
ft
Maximum:
11.5 + 2.5%
40
2.5
700
---
550
10,000
Rectifier
Test condition:
11.5
---
---
---
---
---
---
_______________________________________________
GENERAL: First Article Inspection - Required. 5/
AMSC N/A
FSC 5960
