INCH-POUND
MIL-PRF-1/1371J
25 August 2010 _
SUPERSEDING
MIL-PRF-1/1371H
16 July 2004
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, THYRATRON
TYPE 7322
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: Triode, hydrogen, ceramic-metal.
See figure 1 and 1/.
Mounting position: Any.
Weight: 2 pounds (907.2 grams) nominal.
ABSOLUTE RATINGS:
Parameter:
Ef
Eres
Ebb
Ecc
epy
epx
egy
egx
Ib
Unit:
V
V ac
V dc
V dc
kv
kv
v
v
A
Maximum:
6.8
6.8
---
-200
25
25
1,500
400
2.0
Minimum:
5.8
5.8
1,500
0
--- 2/
5% epy 3/
500 4/
--- 5/
---
Test conditions:
6.3
6.3
---
0
25
---
450
---
---
ABSOLUTE RATINGS:
Parameter:
Ip
ib
dik/dt
Pb
prr
tj
tk
TA
Cooling
a/µs
µs
°C
Unit:
A ac
a
---
---
sec
---
9
Maximum:
36
1,000
5,000
---
0.005
---
+125
6/
20 x 10
Minimum:
---
---
---
---
---
---
---
-55
---
Test conditions:
---
---
---
---
500
---
600
Ambient
---
See footnotes at end of table I.
________________________________
GENERAL:
Qualification: Not required.
AMSC N/A
FSC 5960
