INCH-POUND
MIL-PRF-1/1350G
25 August 2010 _
SUPERSEDING
MIL-PRF-1/1350 F
16 July 2004
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, POWER
TYPE 8295A
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: Pentode, external anode, ceramic-metal.
See figure 1.
Mounting position: Any.
Weight: 3 pounds (1.36 kg) nominal.
ABSOLUTE RATINGS:
Parameter:
F
Ef
Eb
Ec1
Ec2
Ec3
Ib
Unit:
MHz
V ac
V dc
V dc
V dc
V dc
mA dc
Class AB1
(rf or audio)
Maximum:
30
6.3
3,000
---
600
100
800
Minimum:
---
5.7
---
---
---
---
---
Test conditions:
---
6.0
2,500
Adj
500
0
400
ABSOLUTE RATINGS:
Anode core and
Parameter:
Ic1
Pp
Pg1
Pg2
tk
seal temp
Cooling
°C
Unit:
mA dc
W
W
W
sec
1/
Class AB1
(rf or audio)
Maximum:
0
1,000
0
30
---
250
---
Minimum:
---
---
---
---
180
---
---
Test conditions:
---
---
---
---
300
---
2/
____________________________________________________________________________________________
GENERAL:
Qualification: Not required.
AMSC N/A
FSC 5960
