MIL-PRF-1/1335H
Dimensions
Ltr
Inches
Millimeters
Min
Max
Min
Max
A
.495
.505
12.57
12.83
B
.745
.755
18.92
19.18
C
.061
.063
1.55
1.60
DIA
DIA
DIA
DIA
D
.199
.201
5.05
5.11
E
.124
.126
3.15
3.20
F
.124
.126
3.15
3.20
G
.124
.126
3.15
3.20
NOTE: Dimensions are in inches.
FIGURE 2. Terminal position gauge.
