INCH-POUND
MIL-PRF-1/1335H
9 JULY 2004
SUPERSEDING
MIL-PRF-1/1335G
14 July 1999
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, NEGATIVE GRID (MICROW AVE)
TYPE 7462
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION:
Triode, metal-ceramic.
See figure 1.
Mounting position: Any.
W eight: 0.06 ounce (1.7 grams) nominal.
ABSOLUTE RATINGS:
Parameter:
Ef
Eb
eb
Ec
egk
Ehk
Unit:
V
V dc
v
V dc
V dc
v
Maximum:
6.6
250
400
0, -50
0
50
Minimum:
6.0
---
---
---
---
---
Test conditions:
6.3
150
---
+6
---
---
ABSOLUTE RATINGS:
Parameter:
Rk
Rg
Ik
Pp
TE
Barometric pressure,
reduced
Unit:
Ohms
Meg
mA dc
W
mm Hg
°C
250 2/
8
0.01 1/
1.1
11.0
Maximum:
---
---
---
---
---
---
Minimum:
---
Test conditions:
910
---
---
---
---
---
See footnotes at end of table I.
GENERAL:
Qualification - Required.
AMSC N/A
FSC 5960
