MIL-PRF-1/1314D
Dimensions
Inches
Millimeters
Inches
Millimeters
Inches
Millimeters
Ltr
Min
Max
Min
Max
Ltr
Min
Max
Min
Max
Ltr
Min
Max
Min
Max
Conformance inspection, part 2
A
4.094
4.344
103.99 110.34
H
.320
.328
8.13
8.33
R
.250
.313
6.35
7.95
B
2.303
2.323
58.50 59.00
J
.181
.191
4.60
4.85
S
.281
.312
7.14
7.92
C
3.047
3.234
77.39 82.14
K
.375
---
9.53
---
T
.188
---
4.78
---
D
1.672
1.765
42.47 44.83
L
.188
---
4.78
---
U
.688
.813
17.48
20.65
E
2.271
2.291
57.68 58.19
M
.063
.125
1.60
3.18
V
.625
.750
15.88
19.05
F
2.115
2.135
53.72 54.23
N
.250
---
6.35
---
W
.344
.406
8.74
10.31
G
1.302
1.322
33.07 33.58
P
1.063 1.125 27.00 28.58
X
---
.047
---
1.19
NOTES:
1. Metric equivalents (to the nearest .01 mm) are given for general information only and are based upon
1 inch = 25.4 mm.
2. Bottom of cup must not be used as a socket stop.
FIGURE 1. Outline drawing of electron tube type 6283.
