INCH-POUND
MIL-PRF-1/1298E
27 July 2010
_
SUPERSEDING
MIL-PRF-1/1298D
23 July 1999
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, PHOTOTUBE
TYPE CE-75V
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION:
Red-infrared sensitive, with a spectral response of S1.
DIMENSIONS AND PIN CONNECTIONS: See figure 1.
ABSOLUTE MAXIMUM RATINGS:
Parameter:
Ebb
Light
Ib
Rp
T
Light source
MegΩ
µA dc
°C
Unit:
V dc
---
m
Maximum:
250
---
15
---
100
---
Test conditions:
250
0.1
---
1.0
---
LS-1 1/
See footnotes at end of table I.
GENERAL:
Qualification Not required.
AMSC N/A
FSC 5960
