INCH-POUND
MIL-PRF-1/1232E
13 January 2012
SUPERSEDING
MIL-E-1/1232D
2 July 1999
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, GAS SWITCHING
TYPE 7166
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: TR, frequency range 1,220 to 1,365 MHz, nominal peak power rating 1.5 Mw.
ABSOLUTE RATINGS:
Parameter:
Incident power
Du
Ebb
Ii
Alt
µA dc
Unit:
Mw
---
V dc
ft
Maximum:
2.0
0.001
---
200
10,000
Minimum:
---
---
-750
100
---
PHYSICAL CHARACTERISTICS:
Dimensions:
See figure 1.
Mounting:
See figure 2. 1/
Weight:
9 pounds (approximate).
TEST CONDITIONS:
Parameter:
Incident power
tp1
tp2
prr
Ii
F
µs
µs
µA dc
Unit:
Mw
pps
MHz
Frequency
± 5%
± 0.15
± 0.15
±
Tolerance:
---
---
---
F
MHz
1
1,220
1%
Test condition 1:
0.50
4.0
1.0
250
100
F3
2
1,255
1%
Test condition 2:
2.00
4.0
---
250
100
F3
3
1,292
1%
1,325
1%
4
5
1,365
1%
See footnotes at end of table I.
GENERAL:
Qualification: Not required
Preproduction sample approval: Required. 2/
This specification sheet uses accept on zero defect sampling in accordance with MIL-PRF-1, table III.
AMSC N/A
FSC 5960
