INCH-POUND
MIL-PRF-1/1178E
22 July 1999
SUPERSEDING
MIL-E-1/1178D(EC)
23 December 1976
PERFORMANCE SPECIFICATION SHEET
ELECTRON TUBE, CATHODE RAY
TYPE 7AGP19
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the electron tube described herein
shall consist of this document and the latest issue of MIL-PRF-1.
DESCRIPTION: A 7.5 inch (190.5 mm) diameter, single beam, electrostatic focus and deflection cathode-ray tube having a
special deflection structure for minimum deflection defocusing.
PIN CONNECTIONS AND DIMENSIONS: See figure 1.
ABSOLUTE RATINGS:
Parameter:
Ef
Ec1
Eb1
Eb2
ed
Rg
Zd
Ehk
Unit:
V
V dc
V dc
V dc
v
Meg
Meg
V dc
± 180
Maximum:
6.9
0
3,500
10,000
2,000
1.5
5.0 1/
---
Minimum:
5.7
-300
----
5.000
---
---
---
Test condition:
6.3
Adjust
Focus
8,000
---
---
---
---
See footnotes at end of table I.
GENERAL:
Qualification - Required.
AMSC N/A
1 of 6
FSC 5960
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
